Product Summary

The AFCT-5944ALZ is a Single Mode SFF Transceiver for SONET OC-48/SDH STM-16 Multirate Operation. It is a high performance, cost effective module for serial optical data communications applications that ranges from 125 Mb/s to 2.7 Gb/s. The AFCT-5944ALZ is designed to provide SONET/SDH compliant links at 2488 Mb/s for short reach links. The module is designed for single mode fiber and operate at a nominal wavelength of 1300 nm. The AFCT-5944ALZ incorporates high performance, reliable, long wavelength optical devices and proven circuit technology to give long life and consistent service. The AFCT-5944ALZ is used in SONET/SDH equipment interconnect, Multirate Client Interface on Metro Gateways and Edge Switches.

Parametrics

AFCT-5944ALZ absolute maximum ratings: (1)Storage Temperature TS: -40 to +85 ℃; (2)Supply Voltage VCC: -0.5 to 3.6 V; (3)Data Input Voltage VI: -0.5 to VCC V; (4)Data Output Current ID: 50 mA; (5)Relative Humidity RH: 0 to 85 %; (6)Receiver Optical Input PINABS: 6 dBm.

Features

AFCT-5944ALZ features: (1)Multirate operation from 125 Mb/s to 2.7 Gb/s; (2)AFCT-5944LZ/ALZ: Links of 2 km with 9/125 μm single mode fiber (SMF); (3)Multisourced 2 × 10 package style with LC receptacle; (4)Single +3.3 V power supply; (5)Temperature range: -40℃ to +85℃; (6)Wave solder and aqueous wash process compatible; (7)Manufactured in an ISO9002 certified facility; (8)RoHS compliant; (9)Fully Class 1 CDRH/IEC 825 compliant; (10)Compliant with ITU-T G.957, STM-16, I-16 and S-16.1 Optical Interfaces; (11)With EMI shield; (12)Receiver output squelch function enabled.
