Product Summary
The EPM3032ATC44 is a low-cost, high-performance EEPROM based on the Altera MAX architecture. Fabricated with advanced CMOS technology, the EPM3032ATC44 operates with a 3.3-V supply voltage and provide 600 to 10,000 usable gates, ISP, pin-to-pin delays as fast as 4.5 ns, and counter speeds of up to 227.3 MHz. The EPM3032ATC44 contains 32 to 512 macrocells, combined into groups of 16 macrocells called logic array blocks (LABs). The EPM3032ATC44 is supported by Altera development systems, which are integrated packages that offer schematic, text-including VHDL, Verilog HDL, and the Altera Hardware Description Language (AHDL)-and waveform design entry, compilation and logic synthesis, simulation and timing analysis, and device programming.
Parametrics
EPM3032ATC44 absolute maximum ratings: (1)Supply voltage:–0.5V to 4.6V; (2)DC input voltage:–2.0V to 5.75V; (3)DC output current, per pin:–25mA to 25mA; (4)Storage temperature:–65℃ to 150℃; (5)Ambient temperature:–65℃ to 135℃; (6)Junction temperature:135℃.
Features
EPM3032ATC44 features: (1)Enhanced ISP algorithm for faster programming; (2)ISP_Done bit to ensure complete programming; (3)Pull-up resistor on I/O pins during in–system programming; (4)High–density PLDs ranging from 600 to 10,000 usable gates ; (5)4.5–ns pin–to–pin logic delays with counter frequencies of up to 227.3 MHz; (6)Hot–socketing support; (7)Programmable interconnect array (PIA) continuous routing structure for fast, predictable performance; (8)Industrial temperature range; (9)PCI compatible; (10)Bus–friendly architecture including programmable slew–rate control; (11)Open–drain output option; (12)Programmable macrocell flipflops with individual clear, preset, ; (13)clock, and clock enable controls; (14)Programmable power–saving mode for a power reduction of over ; (15)50% in each macrocell; (16)Configurable expander product–term distribution, allowing up to ; (17)32 product terms per macrocell.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 EPM3032ATC44-10 |
|
IC MAX 3000A CPLD 32 44-TQFP |
Data Sheet |
|
|
||||||
|
EPM3032ATC44-10N |
|
IC MAX 3000A CPLD 32 44-TQFP |
Data Sheet |
|
|
||||||
|
EPM3032ATC44-4 |
|
IC MAX 3000A CPLD 32 44-TQFP |
Data Sheet |
|
|
||||||
|
EPM3032ATC44-4N |
|
IC MAX 3000A CPLD 32 44-TQFP |
Data Sheet |
|
|
||||||
|
EPM3032ATC44-7 |
|
IC MAX 3000A CPLD 32 44-TQFP |
Data Sheet |
|
|
||||||
|
EPM3032ATC44-7N |
|
IC MAX 3000A CPLD 32 44-TQFP |
Data Sheet |
|
|
||||||
