PIC18F25J10-I

RISC Microcontroller, 28SOIC, 40MHz, 8-Bit, 2.7 V ~ 3.6 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.40~2.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.40~2.30

PartNumber:: PIC18F25J10-I

Brand:: Microchip Technology - Microchip | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Mr Maxisua zhou's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-02-01

From Other Seller

Part Number:PIC18F25J10-I
US $1.40 - 2.30
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The PIC18F25J10-I is a 28-Pin High-Performance, RISC Microcontroller with nanoWatt Technology.

Parametrics

PIC18F25J10-I absolute maximum ratings: (1)Ambient temperature under bias: -40 to +100℃; (2)Storage temperature: -65 to +150℃; (3)Voltage on any digital-only input MCLR I/O pin with respect to VSS: -0.3V to 6.0V; (4)Voltage on any combined digital and analog pin with respect to VSS: -0.3V to (VDD + 0.3V); (5)Voltage on VDDCORE with respect to VSS: -0.3V to 2.75V; (6)Voltage on VDD with respect to VSS: -0.3V to 4.0V; (7)Total power dissipation: 1.0W; (8)Maximum current out of VSS pin: 300 mA; (9)Maximum current into VDD pin: 250 mA; (10)Input clamp current, IIK (VI < 0 or VI > VDD): 0 mA; (11)Output clamp current, IOK (VO < 0 or VO > VDD): TBD; (12)Maximum output current sunk by any PORTB and PORTC I/O pin: 25 mA; (13)Maximum output current sunk by any PORTA, PORTD, and PORTE I/O pin: 4 mA; (14)Maximum output current sourced by any PORTB and PORTC I/O pin: 25 mA; (15)Maximum output current sourced by any PORTA, PORTD, and PORTE I/O pin: 4 mA; (16)Maximum current sunk by all ports combined: 200 mA; (17)Maximum current sourced by all ports combined: 200 mA.

Features

PIC18F25J10-I features: (1)Operating voltage range: 2.0V to 3.6V; (2)5.5V tolerant input (digital pins only); (3)On-chip 2.5V regulator; (4)Low-power, high-speed CMOS Flash technology; (5)C compiler optimized architecture: Optional extended instruction set designed to optimize re-entrant code; (6)Priority levels for interrupts; (7)8 × 8 Single-Cycle Hardware Multiplier; (8)Extended Watchdog Timer (WDT): Programmable period from 4 ms to 131s; (9)Single-Supply In-Circuit Serial Programming (ICSP) via two pins; (10)In-Circuit Debug (ICD) with three Break points via two pins; (11)Power-Managed modes: Run: CPU on, peripherals on; Idle: CPU off, peripherals on; Sleep: CPU off, peripherals off.
