AP1117Y33G-13DITR-ND

low dropout, positive, adjustable or fixed-mode regulator, 3.3V, 1A, SOT89-3

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.45~0.64 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.45~0.64

PartNumber:: AP1117Y33G-13DITR-ND

Brand:: Diodes Incorporated - Diodes | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Mr Maxisua zhou's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-23

From Other Seller

Part Number:AP1117Y33G-13DITR-ND
US $0.45 - 0.64
AT45DB161B-TI

US $0.90 - 2.00 / Piece
(0) Remove
AT24C02BN-SH-T

US $0.08 - 0.15 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AP1117Y33G-13DITR-ND is a low dropout positive adjustable or fixed-mode regulator with 1A output current capability. The product is voltage specifically designed to provide well-regulated supply for low IC applications such as high-speed bus termination and low current 3.3V logic supply. The AP1117Y33G-13DITR-ND is also well suited for other applications such as VGA cards. The AP1117Y33G-13DITR-ND is guaranteed to have lower than 1.4V dropout at full load current making it ideal to provide well-regulated outputs of 1.25 to 5.0 with 6.4V to 18V input supply. The applications of the AP1117Y33G-13DITR-ND include PC Peripheral, Communication.

Parametrics

AP1117Y33G-13DITR-ND absolute maximum ratings: (1)DC Supply Voltage: -0.3 to 18 V; (2)Operating Junction Temperature Range (Commercial Grade): 0 to +125 ℃; (3)Maximum Junction Temperature: 150℃; (4)Power Dissipation: Internally limited by maximum junction temperature of 150 ℃; (5)Storage Temperature: -65 to +150 ℃.

Features

AP1117Y33G-13DITR-ND features: (1)1.4V Maximum Dropout at Full Load Current; (2)Fast Transient Response; (3)Output Current Limiting; (4)Built-in Thermal Shutdown; (5)Good Noise Rejection; (6)3-Terminal Adjustable or Fixed 1.5V, 1.8V, 2.5V, 3.3V, 5.0V; (7)SOT223-3L, TO252-3L, SOT89-3L, TO263-3L and TO220-3L Packages; (8)SOT223-3L and TO252-3L: Available in "Green" Molding Compound (No Br, Sb); (9)Lead Free Finish/RoHS Compliant.
