Product Summary

The H8-3002 is a microcontroller (MCU) that integrates system supporting functions together with an CPU core having an original Hitachi architecture. The CPU of H8-3002 has a 32-bit internal architecture with sixteen 16-bit general registers, and a concise, optimized instruction set designed for speed. H8-3002 can address a 16-Mbyte linear address space. Four MCU operating modes of H8-3002 offer a choice of data bus width and address space size.

Parametrics

H8-3002 absolute maximum ratings: (1)Power supply voltage VCC: –0.3 to +7.0 V; (2)Input voltage (except port 7) Vin: –0.3 to VCC +0.3 V; (3)Input voltage (port 7) Vin: –0.3 to AVCC +0.3 V; (4)Reference voltage VREF: –0.3 to AVCC +0.3 V; (5)Analog power supply voltage AVCC: –0.3 to +7.0 V; (6)Analog input voltage VAN: –0.3 to AVCC +0.3 V; (7)Operating temperature Topr Regular specifications: –20 to +75 ℃; (8)Wide-range specifications: –40 to +85 ℃; (9)Storage temperature Tstg: –55 to +125 ℃.

Features

H8-3002 features: (1)Sixteen 16-bit general registers; (2)Maximum clock rate: 17 MHz; (3)Add/subtract: 118 ns; (4)Multiply/divide: 824 ns; (5)Address space can be partitioned into eight areas, with independent bus specifications in each area; (6)Chip select output available for areas 0 to 3; (7)8-bit access or 16-bit access selectable for each area; (8)Two-state or three-state access selectable for each area; (9)Selection of four wait modes; (10)Bus arbitration function.

Diagrams

H8-3002 block diagram
