Product Summary

The TJM4558CDT is a high performance monolithic dual operational amplifier. The circuit combines all the outstanding features of the MC1458 and, in addition possesses three times the unity gain bandwidth of the industry standard.

Parametrics

TJM4558CDT absolute maximum ratings: (1)Supply Voltage: ±22 V; (2)Input Voltage: ±15 V; (3)Differential Input Voltage: ±30 V; (4)Power Dissipation: 680 mW; (5)Output Short Circuit Duration: Infinite; (6)Operating Free-Air Temperature Range: 0 to +70 ℃; (7)Storage Temperature: -65 to +150℃.

Features

TJM4558CDT features: (1)Internally compensated; (2)Short-circuit protection; (3)Gain and phase match between amplifier; (4)Low power consumption; (5)Pin to pin compatible with MC1458/LM358; (6)Gain bandwidth product( at 100kHz) 5.5MHz.

Diagrams

TJM4558CDT schematic diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
TJM4558CDT
TJM4558CDT
STMicroelectronics
Operational Amplifiers - Op Amps Dual Bipolar Oper Amps Wide bandwidth
Data Sheet
0-1: $0.47
1-10: $0.40
10-100: $0.32
100-250: $0.28
