Product Summary

The TL103WIDR is a dual operational amplifier with internal reference. The TL103WIDR combines the building blocks of a dual operational amplifier and a fixed voltage reference - both of which often are used in the control circuitry of both switch-mode and linear power supplies. The applications of the TL103WIDR are Battery Chargers, Switch-Mode Power Supplies, Linear Voltage Regulation, Data-Acquisition Systems.

Parametrics

TL103WIDR absolute maximum ratings: (1)Supply voltage:36V; (2)Operational amplifier input differential voltage:36V; (3)Operational amplifier input voltage range:-0.3V to 36V; (4)Voltage reference cathode current:100mA; (5)Package thermal impedance:97℃/W; (6)Maximum junction temperature:150℃; (7)Storage temperature range:-65 to 150℃.

Features

TL103WIDR features: (1)Low Offset Voltage Max of: 4 mV (25℃) and 5 mV(Full Temperature); (2)Low Supply Current:350 μ A/Channel (Typ); (3)Unity Gain Bandwidth:0.9 MHz (Typ); (4)Input Common-Mode Range Includes GND; (5)Large Output-Voltage Swing: 0 V to V CC – 1.5 V; (6)Wide Supply-Voltage Range:3 V to 32 V; (7)2-kV ESD Protection (HBM); (8)Low Temperature Drift:7 mV (Typ) Over; (9)Operating Temperature Range; (10)Wide Sink-Current Range:0.5 mA (Typ) to 100 mA; (11)Output Impedance:0.2 Ω (Typ).

Diagrams

TL103WIDR pin configuration

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
TL103WIDR
TL103WIDR

Texas Instruments

Operational Amplifiers - Op Amps Dual OpAmp w/Internal Reference

Data Sheet

0-1: $0.35
1-25: $0.28
25-100: $0.24
100-250: $0.21
TL103WIDRE4
TL103WIDRE4

Texas Instruments

Operational Amplifiers - Op Amps Dual OpAmp w/Internal Reference

Data Sheet

0-1: $0.38
1-25: $0.30
25-100: $0.26
100-250: $0.23
TL103WIDRG4
TL103WIDRG4

Texas Instruments

Operational Amplifiers - Op Amps Dual Op Amp W/ Internal Ref

Data Sheet

0-1: $0.38
1-25: $0.30
25-100: $0.26
100-250: $0.23
