W83791G

48-pin LQFP, External Sensor, 4.5 V to 5.5 V, Hardware Monitor, H/W IC, 8-bit ADC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $4.20~5.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $4.20~5.00

PartNumber:: W83791G

Brand:: Nuvoton Technology Corporation - Nuvoton | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Mr Maxisua zhou's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-01-04

From Other Seller

Part Number:W83791G
US $4.20 - 5.00
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
YL-G709

US $65.00 - 68.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The W83791G is an evolving version of the W83782G. Besides the conventional functions of W83782G, W83791G uniquely provides several innovative features such as speech function, ASF sensor compliant, SMBus 2.0 ARP command compatible, VID table selection trapping, and 5VID output control. An 8-bit analog-to-digital converter (ADC) was built inside W83791G. W83791G can simultaneously monitor 10 analog voltage inputs (including power VDD/5VSB monitoring), 5 fan tachometer inputs, 3 remote temperatures, and one case open detection signal.

Parametrics

W83791G absolute maximum ratings: (1)Power Supply Voltage: -0.5 to 7.0V ; (2)Input Voltage: -0.5 to VDD+0.5V ; (3)Operating Temperature: 0 to +70℃; (4)Storage Temperature: -55 to +150℃.

Features

W83791G features: (1)Support System Management Bus (SMBus) version 2.0 specification; (2)Comply with hardware sensor slave ARP (Address Resolution Protocol); (3)Response sensor type ARP command; (4)Response ASF command --- Get Event Data , Get Event Status; (5)Build in 8-bit current D/A converter; (6)1 CPU present or absent trigger input; (7)5 External trigger inputs; (8)128 Internal programmable trigger inputs; (9)17 H/W Monitor event trigger inputs; (10)Programmable 0-255 seconds timeout trigger inputs for firmware or software; (11)Instruction cycle is <= 400 uS typically; (12)Section control provided in each voice section; (13)External resistor for ring oscillator 2.4 Actions Enabling; (14)Beep tone warning separated speech output; (15)Issue SMI#, OVT#, IRQ signals to activate system protection; (16)CPU Voltage ID reading; (17)VID output control; (18)Enhance beep warning by detecting Intel VRM 9.0 VID 2.6 General ; (19)I2CTM serial bus interface; (20)5 VID input pins for CPU VCORE identification (for PentiumTM II/III); (21)Initial power fault beep (for +3.3V, VCORE); (22)Internal clock Oscillator with 3M Hz; (23)5V VSB operation; (24)48-pin LQFP.
